H.264 Satellite Receiver Asi Decoder With Multiple Streaming Channels

Multi-channel Decoder GC-1803B H.264 satellite receiver with multiple streaming channels ASI Decoder

GC-1803B

Multi-channel Decoder GC-1803B H.264 satellite receiver with multiple streaming channels ASI Decoder

Multi-channel decoder GC-1803B, a new generation of Gaussian decoding equipment, supports DTMB radio frequency input, ASI input or IP input, decodes 8 sets of programs in the input stream, and then outputs through the AV interface, mainly used for digital TV The front-end computer room of the network operator serves as the receiving, processing and decoding equipment for the external digital TV source.

Main Features

• Ø ASI input interface supports burst and uniform input stream

  Ø IP interface supports UDP/RTP TS stream

  Ø ASI input code rate ≥120Mbps

  Ø DTMB RF input frequency range 54.000~860.000MHz

  Ø Can automatically detect the bit rate of the input stream

  Ø The input TS of up to 64 programs can be analyzed

  Ø The decoded video format supports H.264/MPEG2/AVS+, and the output interface is composite video (CVBS)

  Ø The decoding audio format supports MPEG1/MPEG2, and the output interface is analog audio (balanced or unbalanced, which can be selected according to needs)

  Ø The decoding supports ASI output, and the output program is the same as CVBS on the same channel.

  Ø Support up to 8 sets of program decoding at the same time

  Ø Support import and export of equipment working parameters

  Ø Support Web network management, all embedded software support remote online upgrade
